CDA34.008 to CDA34.032
Designation
Technical data
CDA34.008
CDA34.010
CDA34.014
CDA34.017
CDA34.024
CDA34.032
Output, motor side
Recommended rated power
with 4-pin standard motor
3.0 kW 4.0 kW 5.5 kW 7.5 kW 11 kW 15 kW
Device rated power 5.7 kVA 7.3 kVA 10.2 kVA 12.4 kVA 17.5 kVA 23.3 kVA
Voltage 3 x 0 ... 400/460 V
Continuous current (RMS) (I
N
)
7.8 A 10 A 14 A 17 A 24 A 32 A
Peak current 1.8 x I
N
for 30 s
14 A 18 A 25 A 31 A 43 A 58 A
Rotating field frequency 0 ... 1600 Hz (> 800 Hz switching frequency = 16 kHz recommended)
Switching frequency of power stage 4, 8, 16 kHz
Input, mains side
Mains voltage 3 x 460 V -25 % +10 %
Asymmetry ±3 % max.
Frequency 50/60 Hz ±10 %
Power loss 150 W 190 W 220 W 270 W 400 W 480 W
Braking chopper power electronics
Peak braking power with int.
braking resistor (only with version
CDA34 ..., Wx.x, BR)
6.0 kW
at 90
Ω
6.0 kW
at 90
Ω
6.0 kW
at 90
Ω
Minimum ohmic resistance of an
externally installed braking resistor
81
Ω 47 Ω 22 Ω
