A-4
CDA3000 Operation Manual
CDA34.045 to CDA34.170
Designation
Technical data
CDA34.045 CDA34.060 CDA34.072 CDA34.090 CDA34.110 CDA34.143 CDA34.170
Output, motor side
Recommended rated power
with 4-pin standard motor
22 kW 30 kW 37 kW 45 kW 55 kW 75 kW 90 kW
Device rated power 32.8 kVA 43.8 kVA 52.5 kVA 65.6 kVA 80 kVA 104 kVA 124 kVA
Voltage 3 x 0 ... 400/460 V
Continuous current (RMS) (I
N
)
45 A 60 A 72 A 90 A 110 A 143 A 170 A
Peak current 1.5 x I
N
for 60s
68 A 90 A 108 A 135 A 165 A 214 A 255 A
Rotating field frequency 0 ... 400 Hz
Switching frequency of power stage 4, 8 kHz
Input, mains side
Mains voltage
3 x 460 V
-25 % +10 %
Asymmetry of mains voltage ±3 % max.
Frequency 50/60 Hz ±10 %
Power loss 600 W 720 W 840 W 1080 W 1320 W 1680 W 2040 W
Braking chopper power electronics
Minimum ohmic resistance of
an externally installed braking
resistor
18
Ω 18 Ω 13 Ω 12 Ω 10 Ω 5.6 Ω 5.6 Ω
