Fitting Instructions – All Glass Hoods
Follow Fitting Instructions for all wall mounted hoods pages…..
Then Continue with this section.
1
After following instructions 1-9 on
pages 18-20 continue with this
section for the rest of the fitting of
Once the hood is assembled and
checked, place your glass directly
on top of the main body section, line
up with the screw holes and secure
Warning: do not over tighten these
screws, they should be hand tight
only. Over tightening may cause the
glass to break
2
After fitting the glass, now fit the
two telescopic chimney section,
please ensure that you do this with
care, slide the top section up to the
fixing bracket, and secure with the
two small screws in the fixing kit.
