Luxair STD Series - Technical Specifications; Electrical and Performance Data

Page
27
Total connected load* . . . . . . . . . 240 W
Fan motor*. . . . . . . . . . . . . . . . . 200 W
Hood lighting . . . . . . . . . . . . ..2 x 20W
Halogen lamps
Osram type 44888 WFL, 20 W
Voltage
UK, NZ, ZA . . . . . . . . . . . . . . .AC 230 V
Frequency . . . . . . . . . . . . . . . . . .50 Hz
Fuse rating (UK). . . . . . . . . . . . . . 3A
AUS, NZ:
Plug rating . . . . . . . . . . . . . . . . . . . 3 A
Test marks . . . . . . . . . .Electrical s afety
. . . . . . . . . . . . . . . . . . . . .. C-Tick Mark
Elec trically suppressed
according to AS/NZS 1044
Electrical cable length . . . . . . . 1.5 mtr
Fan performance wall mounted
hoods
Extraction power according to
EN 61591
0
Extraction sys tem
150 mm:
Level I . . . . . . . . . . . . . . . . . . .200 m/h3
Level II. . . . . . . . . . . . . . . . . . .300 m/h3
Level III . . . . . . . . . . . . . . . . . . 650 m/h3
0
Extraction sys tem
125 mm:
Level I . . . . . . . . . . . . . . . . . . .180 m/h3
Level II. . . . . . . . . . . . . . . . . . .280 m/h3
Level III . . . . . . . . . . . . . . . . . . 550 m/h3
Unrestricted . . . . . . . . . . . . . . .680 m/h3
* For EXT models, the connected load
and ex traction power will depend on
the type of external motor fitted.
EXT models:
Length of connection cable to external
motor . . . . . . . . . . . . . . . . . . . . . . .1.9 m
Decibel ratings
Noise Level Min/Max (CBM/H) Speed 1 = 37.5DB
Speed 2 = 46.9DB
Speed 3 = 56.9DB
Fan performance Island Hoods
0
Extraction system 125 mm:
Level I . . . . . . . . . . . . . . . . . . .280 m/h3
Level II. . . . . . . . . . . . . . . . . . .380 m/h3
Level III . . . . . . . . . . . . . . . . . . 800 m/h3
Unrestricted . . . . . . . . . . . . . . .890 m/h3
Technical Information:
