High
Cut
Filter
(HIGH
CUT)
OFF
at
the
centre
position.
When
moved
up
to
the
7KHz
posi-
tion,
the
amount
of
high
frequencies
is
reduced
sharply
at
the
rate
of
6
dB/oct.
When
moved
down
to
the
12KHz
position,
the
roll-off
starts
at
12KHz
For
further
details,
refer
to
High
Cut
Filter
(Page
16).
@
Tape
Monitor
Switch
(MONITOR)
The
input
function
selector
(phono,
AUX,
etc.)
is
separated
from
the
volume
and
tone
contro]
section.
If
a
tape
recorder
is
not
connected,
and
this
switch
is
moved
from
NORMAL
to
either
of
the
tape
inputs,
no
sound
will
be
heard.
In
case
a
3-head
tape
recorder
is
used,
simultaneous
playback
monitoring
is
possible
while
recording.
In
this
case,
the
amplifier
receives
the
playback
signals
either
from
the
Tape
Monitor
terminals
(32,
34),
the
Tape
Connector
(23)
or
the
tape
reproduction
jack
(17),
while
at
the
same
time
feeding
the
recording
signals
to
the
Recording
Output
terminals
(31,
33),
the
Tape
Connector
(23),
or
DECK-
1
recording
jack
(18).
In
case
a
matrix
4-CH
decoder
is
connect-
ed
to
the
DECK-2
Monitor
(34)
and
Recording
Output
terminals
(33),
this
lever
switch
must
be
set
at
the
DECK-2/4ch
position.
Eor
further
details,
refer
to
Connection
of
4-CH
DECODER
(Page
17)-
Tape
Dubbing
Switch
(DUBBING)
Tape
dubbing
(reprinting)
is
possible
with
this
switch.
When
the
leveris
set
at
the
“1
to
2”
position,
the
playback
sound
of
the
DECK-1
terminals
can
be
printed
on
DECK-2,
and
vice
versa
when
set
at
the
2
to
1°”
position.
While
in
the
dubbing
process,
it
is
possible
to
monitor
with
the
Tape
Monitor
Switch
(12).
Except
when
reprinting
a
tape,
it
is
recommended
that
this
switch
be
set
at
the
centre,
SOURCE
position.
@
Pilot
Lamp
This
lamp
indicates
that
the
Mains
Switch
(2)
and
the
electric
current
are
On.
:
®
Input
Selector
Switch
This
switch
permits
proper
selection
of
desired
programme
sources
(Phono-1,
Phono-2,
Tuner,
Aux-1,
Aux-2).
@
Mode
Selector
Switch
Use
this
switch
for
selecting
reproduction
modes
such
as
Stereophonic
or
Monaural.
For
further
details,
refer
to
Mode
Selection
(Page
14).
@
DECK-1
Reproduction
Jack
(IN)
This
jack
has
a
function
equivalent
to
that
of
the
Deck-1
Moni-
tor
terminals
(32)
on
the
rear
panel.
Plug
in
the
line
output
of
the
tape
recorder,
and
you
can
monitor
by
setting
the
Monitor
Switch
(12)
at
the
““deck-1"
position.
@
DECK-1
Recording
Jack
(OUT)
This
jack
hes
a
function
equivalent
to
that
of
the
Deck-1
Re-
cording
Output
terminals
(31).
Recording
output
is
always
a-
vailable
from
this
jack
in
so
far
as
an
input
is
given
to
the
amplifier.
If
the
Dubbing
Switch
(13)
is
set
at
the
‘2
to
1”
posi-
tion,
this
jack
will
be
connected
with
the
Deck-2
Monitor
termi-
nals,
and
recording
output
will
be
available
from
the
Deck-2
terminals
(33).
©
Attenuator
(ATTENUATE)
Adjustment
of
this
control
makes
it
possible
to
pre-set
efficiency
of
the
Volume
contro!
(20)
in
the
range
of
0
dB
to
—18
dB
(about
).
Also,
since
this
attenuator
is
placed
at
the
entrance
of
the
main
amplifier
section,
it
can
be
used
as
an
input
level
setter
for
independent
use
of
the
main
amplifier
section.
@
Volume
Control
(VOLUME)
A
clockwise
turn
of
this
control
increases
volume,
while
a
counter-clockwise
turn
decreases
and
finally
cuts
out
volume.
@
Balance
Control
(BALANCE)
The
volume
balance
on
right
and
left
channels
can
be
adjusted
with
this
control.
Turn
it
clockwise,
and
the
volume
of
the
left
channel
will
decrease;
counter-clockwise
causes
a
dectease
of
the
right
channel.
When
the
volume
of
both
channels
is
balanced,
monaural
reproduction
sound
comes
from
the
centre
of
both
right
and
left
speakers.
This
point
is
usually
obtained
by
setting
the
click-stopper
at
its
centre
point.
