Quick Install Guide
XFS-1084P
HARDWARE DESCRIPTION
Front Panel
The front panel of the XFS-1084P includes 8 Link/Activity LEDs, one
power LED, four PoE Status LEDs and one PoE Max LED. Please refer to
the detailed description of these indicators in Section 2.2 below.
XFS-1084P Front Panel View
LED Indicators
The LED indicators of the XFS-1084P include 8 Link/Activity LEDs,
one power LED, four PoE Status LEDs and one PoE Max LED. These
LED indicators show the operating status of the XFS-1084P and
each switch connection.
The following chart shows the LED indicators of the XFS-1084P along
with an explanation of the indicator’s properties:
