Quick Install Guide
XFS-1084P
Rear Panel Layout
The Rear Panel of the XFS-1084P includes eight 10/100Mbps RJ-45
Ethernet ports and one DC power port used for DC power input.
XFS-1084P Rear Panel View
CAUTION: Please use the included power supply. If a
different power supply is used, it could damage
the XFS-1084P
PREPARING FOR INSTALLATION
System Requirements
Ethernet Cables to connect the XFS-1084P to Ethernet
enabled devices
Power should be 48VDC @ 1.25A
To Next Page
