Quick Install Guide
If any of the listed items are missing or damaged, please contact the reseller from whom you
purchased for return/replacement.
HARDWARE DESCRIPTION
Front Panel
The front panel of the XMS-1008P switch includes 8 1000Mbps RJ45 and 2 SFP expansion
ports on the right side and LED indicators on the left side. Each 1000Mbps port has one
Link/Activity LED, one 1000Mbps LED and one POE LED, there are also two SFP LEDs, one
Power LED, one System LED and a reset button.
XMS-1008P Front Panel
Status indicators
Each port has one Link/Activity LED, one 1000Mbps LED and one POE LED. In addition, there
are two SFP LEDs, one Power LED, one System LED, as well as a Reset button to reboot the
device or restore factory default settings. The green LED indicators show the working status
of the switch. The following table describes the LED functionality:
