Simply Connected
© 2014 Luxul. All Rights Reserved.
Other trademarks and registered trademarks are the property of their respective owners
5
Network Ports
There are 8 10/100/1000Mbps RJ-45 ports (Ports 1~8), that support Auto MDI/MDIX.
Two Gigabit SFP optical/copper module expansion ports with support for hot-swapping of the
SFP modules.
NOTE: The SFP expansion ports cannot support optical connections until
equipped with an SFP (Mini GBIC) optical module.
NOTE:
When powering up, the port LEDs corresponding to the optical
interface may take a moment to initialize. This is normal as the
XMS-1008P does not detect the optical connection until after the
initialization and startup of internal software systems are completed.
NOTE: To extend your wired network connections beyond 300 feet, an optical
connection will be required. Please contact your Luxul representative or
go to our website to learn more about optical fiber, SFP optical modules
and optical network installation.
Rear Panel
The rear panel provides an AC input socket and power on/off switch. Use the included
power cable to connect the XMS-1008P to a surge protected outlet. The built-in high-
performance switching power supply of the XMS-1008P supports an input range of: AC 100 V
~ 220V, 50 Hz ~ 60 HZ.
INSTALLATION PREPARATION
System and Environmental Requirements
Network cables to connect the XMS-1008P to Ethernet enabled devices
A computer supporting TCP/IP and equipped with a Web browser. Supported Web browser
versions include Microsoft IE 7.0 and up, Safari 1.0 and up or Mozilla Firefox 1.0 and up. The Web
browser is used to configure the XMS-1008P.
Power must be AC 100V ~ 220V, 50Hz ~ 60Hz.
Temperature of the operating environment should be: 32F~113F (0C~45C). Place the switch away
from heat generating devices. For best performance and heat dissipation/ventilation, make sure
there is adequate space around the switch.
Humidity of the operating environment should be: 5%-95% non-condensing. Do not place the
switch in an extremely dirty or damp location.
Keep the switch away from strong electromagnetic fields (i.e. Air Conditioner compressors, fluores-
cent light ballasts, CRT monitors/televisions, etc.), and free from vibration, dust and direct sun light.
