Lynx 5000 Series User Manual

R FR 5018 Reference Manual. Rev 1.0
Page 16 of 24
Power Supply LED Indicators
The Table below shows the error conditions for the LED on the power supply units.
These are visible through the ventilation holes on the left side of the front of the rack
Fan Alarm LED
The Table below shows the error conditions for the LED on the fan front cover of the
R FR 5018. This is visible on the upper center of the front of the rack
LED Color
Condition
Green
Normal Operation
Yellow
Warning: High Temperature
Red Flashing
Warning: Voltage out of range
Red Continuous
Warning: Over Temperature
Off
Failure: Exchange Supply
LED Color
Condition
Green
Normal Operation, all fans working
Yellow
1 or more fans failed
Red Continuous
all fans failed
