Lynx 5000 Series User Manual

R FR 5018 Reference Manual. Rev 1.0
Page 24 of 24
Specifications
Mechanical
Size
2 RU high x 325 mm deep including connectors and front cover.
31 cm without front cover. Standard 19” rack mount.
Weight (empty)
4,9 kg with single power supply
Connections
All connections made on rear of rack
Performance
Available Card Slots
10 x CardModules (single width backplanes)
1 x Controller
2 x Power Supplies (primary and optional redundant)
Power Indication
(alarm)
One multifunction LED per supply and GPO output
Fan Alarm through front cover Module alarm LEDs visible
through front cover
Controller alarm
LED bar
Connections (rear connections)
LAN Connector
RJ 45 (10/100 Base T)
Alarm Connector
Terminal strip
Alarm Major and Minor: Relay contact closures
Ref In
BNC connection for rack reference, with active loop output
Primary AC
Standard IEC 60320 C13 AC power connector,
double pole fused (2A)
Redundant AC
Standard IEC 60320 C13 AC power connector,
double pole fused (2A)
Electrical Specifications
Power Input
100 – 240VAC, 50Hz – 60Hz. Two separate and isolated
connections for Primary and Redundant supplies.
Power Consumption
180W max.
Safety
IEC 60950-1:2005/ EN 60950-1:2006/VDE 0805-1
Ambient
Temperature
5°C to 40°C Maintaining specifications
0°C to +50°C Operating
Humidity
Max 90% non-condensing
Altitude
up to 2000m
Supplied Accessories
Documentation
Reference Manual CD

Lynx 5000 Series Specifications
