R FR 5018 Reference Manual. Rev 1.0
Page 21 of 24
Locking
Clip
Front Cover Removal
The Front Cover with the integrated fans opens easily releasing the two locking clips.
Push the locking clips from top and bottom and pull the front cover forward.
Locking
Clip
PUSH
PUSH
PUSH
PUSH
PUSH
PUSH
