Lynxspring ONYXX LX BZ424-LX User Manual

Sequence of Operation Details
PidRoomT_Htg
 P = 20
 I = 0.05
 Bias = 0
 Rever
se
100
PidRoomT_Clg
ActiveRTSP_Clg + 5
 P = 20
 I = 0.05
 Bias = 0
 Dir
ect
Ac
tiveR
TSP_Htg - 5 ActiveRTSP_Htg
ActiveRTSP_Clg
RoomT
PidHL_DST
DSHL_SP - 10
DSHL_SP
DSsupplyT
DSHL_SP + 10
 P = 5
 I = 0.1
 Bias = 50
 Rever
se
100
50
0
P
idLL_DST
D
SLL_SP
DSsupplyT
DSLL_SP + 10
 P = 5
 I = 0.1
 Bias = 50
 Dir
ect
100
0
50
DSLL_SP - 10
PidRoomTz2_Htg
 P = 20
 I = 0.05
 Bias = 0
 Rever
se
100
PidRoomTz2_Clg
 P = 20
 I = 0.05
 Bias = 0
 Dir
ect
P
i
dR
oom
Tz
3
_Htg
 P = 20
 I = 0.
05
 Bi
a
s = 0
 R
ev
er
se
100
PidRoomTz3_Clg
 P = 20
 I = 0.05
 Bias = 0
 Dir
ect
Ac
tiveT
z2SPHtg - 5 ActiveTz2SPHtg ActiveTz2SPClg ActiveTz2SPClg + 5 ActiveTz3SPHtg - 5 ActiveTz3SPHtg ActiveTz3SPClg ActiveTz3SPClg + 5
Tzone2 Tzone3
www.lynxspring.com

Lynxspring ONYXX LX BZ424-LX Specifications

Power

power supply voltage	24 VAC/VDC ± 15%
current consumption	5 VA
maximum current consumption	48 VA
voltage range	0 - 10 Vdc
current range	0 - 20 mA

Mechanical

dimensions	4.9” x 8.5” x 2.5”
dimensions (metric)	123 mm X 215 mm X 63 mm
weight	744 g / 1.5 lb
noise level	35 dB(A)
shaft diameter	1/4” to 5/8” [6mm to 16mm]

Operating Environment

stocking temperature range	-30 °C to 50 °C / -22 °F to 122 °F
operating temperature range	-25 °C to 45 °C / -13 °F to 113 °F
operating humidity range	10% to 90% H.R. without condensation

Internal Components

microprocessor	STM32 (ARM CortexTM M3) 32 bits
cpu speed	72MHz
memory	768 KB non-volatile Flash
ram	96 KB RAM
