Lynxspring ONYXX LX BZ424-LX User Manual

PID Loops
Object
Instance
Object name Description Action Kp Ki Bias
LOOP0
zPidFlow Flow control PID loop Reverse 0.3 0.01 50
LOOP1
PidRoomT_Clg
Room T° control loop, cooling
Direct 20 0.05 0
LOOP2
PidRoomT_Htg
Room T° control loop, heating
Reverse 20 0.05 0
LOOP3
PidHL_DST Downstream high limit control loop Reverse 5 0.1 50
LOOP4
PidLL_DST Downstream low limit control loop Direct 5 0.1 50
LOOP6
PidRoomTz2_Clg
Room T° control loop, cooling
Direct 20 0.05 0
LOOP7
PidRoomTz2_Htg
Room T° control loop, heating
Reverse 20 0.05 0
LOOP8
PidRoomTz3_Clg
Room T° control loop, cooling
Direct 20 0.05 0
LOOP9
PidRoomTz3_Htg
Room T° control loop, heating
Reverse 20 0.05 0
www.lynxspring.com

Lynxspring ONYXX LX BZ424-LX Specifications

Power

power supply voltage	24 VAC/VDC ± 15%
current consumption	5 VA
maximum current consumption	48 VA
voltage range	0 - 10 Vdc
current range	0 - 20 mA

Mechanical

dimensions	4.9” x 8.5” x 2.5”
dimensions (metric)	123 mm X 215 mm X 63 mm
weight	744 g / 1.5 lb
noise level	35 dB(A)
shaft diameter	1/4” to 5/8” [6mm to 16mm]

Operating Environment

stocking temperature range	-30 °C to 50 °C / -22 °F to 122 °F
operating temperature range	-25 °C to 45 °C / -13 °F to 113 °F
operating humidity range	10% to 90% H.R. without condensation

Internal Components

microprocessor	STM32 (ARM CortexTM M3) 32 bits
cpu speed	72MHz
memory	768 KB non-volatile Flash
ram	96 KB RAM
