Lynxspring ONYXX LX BZ424-LX User Manual

Analog Values
Object
Instance
Description Default value
Tags
Minimum
range value
Maximum
range value
Object name
AV0
zRunTime Running time of the actuator (floating)
95 sec
Cfg
30 sec
480 sec
AV1
zDeadband Deadband of the actuator
1 %
Cfg
1 % 5 %
AV2
zActiveFlowSP Active flow setpoint
---
Status
0 CFM 2000 CFM
AV3
MaxAFpos Maximum airflow (or position)
1000 CFM Cfg 0 CFM 2000 CFM
AV4
MinAFpos Minmum airflow (or position)
100 CFM Cfg 0 CFM 2000 CFM
AV5
MinAFpos_Htg Min. AF (or position) @ 100% heating
150 CFM Cfg 0 CFM 2000 CFM
AV6
MinAFpos_Clg Min. AF (or position) @ 100% cooling
100 CFM Cfg 0 CFM 2000 CFM
AV10
RTSPmin_Occ
Minimum Room T° setpoint
59°F (15°C) Cfg 32°F (0°C) 122°F (50°C)
AV11
RTSPmax_Occ
Maximum Room T° setpoint
82°F (28°C) Cfg 32°F (0°C) 122°F (50°C)
AV12
RTSPclg_Occ
Room T° cooling setpoint, occupied
--- User 32°F (0°C) 122°F (50°C)
AV13
RTSPhtg_Occ
Room T° heating setpoint, occupied
--- User 32°F (0°C) 122°F (50°C)
AV14
RTSP_DeadBand RTSP deadband between Clg and Htg
1.8°F (1°C) Cfg 1.8°F (1°C) 18°F (10°C)
AV15
RTSPclg_Unocc
Room T° cooling setpoint, unoccupied
80°F (27°C) User 32°F (0°C) 122°F (50°C)
AV16
RTSPhtg_Unocc
Room T° heating setpoint, unoccupied
65°F (18°C) User 32°F (0°C) 122°F (50°C)
AV17
RTSPclg_STBdt Standby mode, RTSP clg offset (pos.)
1.8°F (1°C) Cfg 1.8°F (1°C) 18°F (10°C)
AV18
RTSPhtg_STBdt Standby mode, RTSP htg offset (neg.)
-1.8°F (-1°C)
Cfg -1.8°F (-1°C) -18°F (-10°C)
AV19
ActiveRTSP_Clg
Active cooling room T° setpoint
--- Status AV10 AV11
AV20
ActiveRTSP_Htg
Active heating room T° setpoint
--- Status AV10 AV11
Please note that objects tagged as:
• Cfg: repr
esent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
www.lynxspring.com

Lynxspring ONYXX LX BZ424-LX Specifications

Power

power supply voltage	24 VAC/VDC ± 15%
current consumption	5 VA
maximum current consumption	48 VA
voltage range	0 - 10 Vdc
current range	0 - 20 mA

Mechanical

dimensions	4.9” x 8.5” x 2.5”
dimensions (metric)	123 mm X 215 mm X 63 mm
weight	744 g / 1.5 lb
noise level	35 dB(A)
shaft diameter	1/4” to 5/8” [6mm to 16mm]

Operating Environment

stocking temperature range	-30 °C to 50 °C / -22 °F to 122 °F
operating temperature range	-25 °C to 45 °C / -13 °F to 113 °F
operating humidity range	10% to 90% H.R. without condensation

Internal Components

microprocessor	STM32 (ARM CortexTM M3) 32 bits
cpu speed	72MHz
memory	768 KB non-volatile Flash
ram	96 KB RAM
