• Dual low-noise mic/instrument preamps with gain controls, LED metering, phantom power and 66dB of available gain
• Two analog inputs and eight analog outputs on 1/4” TS jacks
• S/PDIF I/O on TOSLink optical or RCA coaxial connectors
• Supports sampling rates from 32KHz, up to 192KHz
• 2-in/8-out analog I/O at 24 bit resolution, up to 96KHz sampling rate
• 24-bit resolution playback at 192KHz sampling rate on outputs 1 and 2
• Two headphone outputs with assignable source and individual level controls
• Software-assigned rotary encoder for tactile control of monitor levels
• 1 x 1 MIDI I/O with hardware bypass switch for computer-independent operation
• Analog outputs support up to 7.1 surround using your audio software (your software must support surround outputs)
• Frequency response 20-40kHz ± 1dB.
• Signal to noise–104dB
• Dynamic range: 108dB (A-weighted)
• THD + N: 0.00281% @ 0dBFS
4. Features and Technical Information
