EM-6485-B Rev.21 P. 26 / 52
SET VALUE. ID PARAMETER
30
31
32
THD I1
THD I2
THD I3
Current total harmonic distortion, Line 1
Current total harmonic distortion, Line 2
Current total harmonic distortion, Line 3
33 THD IN Neutral current total harmonic distortion
34
35
36
THD U12
THD U23
THD U31
Delta voltage total harmonic distortion, 1 – 2
Delta voltage total harmonic distortion, 2 – 3
Delta voltage total harmonic distortion, 3 – 1
37
38
39
THD U1N
THD U2N
THD U3N
Phase voltage total harmonic distortion, Phase 1
Phase voltage total harmonic distortion, Phase 2
Phase voltage total harmonic distortion, Phase 3
43 T-Q Reactive power for bidirectional current
44 T-PF Power factor for bidirectional current
■ ∑ VIEW DISPLAY PARAMETER SETTING 2.00
ADDR. WORD PARAMETER
7393 1 ∑1, Line 1 - Measurand to be assigned - Refer to the table below.
7394 1 ∑1, Line 2 - Measurand to be assigned - Refer to the table below.
7395 1 ∑1, Line 3 - Measurand to be assigned - Refer to the table below.
7397 1 ∑2, Line 1 - Measurand to be assigned - Refer to the table below.
7398 1 ∑2, Line 2 - Measurand to be assigned - Refer to the table below.
7399 1 ∑2, Line 3 - Measurand to be assigned - Refer to the table below.
7401 1 ∑3, Line 1 - Measurand to be assigned - Refer to the table below.
7402 1 ∑3, Line 2 - Measurand to be assigned - Refer to the table below.
7403 1 ∑3, Line 3 - Measurand to be assigned - Refer to the table below.
7405 1 ∑4, Line 1 - Measurand to be assigned - Refer to the table below.
7406 1 ∑4, Line 2 - Measurand to be assigned - Refer to the table below.
7407 1 ∑4, Line 3 - Measurand to be assigned - Refer to the table below.
■ ∑ VIEW MEASURANDS AND SELECTABLE POSITIONS (lines, ✓ = selectable) 2.00
SET VALUE. ID PARAMETER UNIT LINE 1 LINE 2 LINE 3
0 NULL Undefined —
✓ ✓ ✓
1 I Current A
✓
2 U Voltage V
✓
3 P Active power W
✓
4 Q Reactive power var
✓
5 S Apparent power VA
✓
6 PF Power factor PF
✓
7 F Frequency Hz
✓
■ SHORTCUT MENU FUNCTION 2.00
ADDR. WORD PARAMETER
7553 1 Resetting alarm trip
0 : Disable
1 : Enable (*)
(*) Factory setting
