EM-6485-B Rev.21 P. 25 / 52
OUTPUT 1
ADDR.
OUTPUT 2
ADDR.
OUTPUT 3
ADDR.
OUTPUT 4
ADDR.
WORD PARAMETER
7029 7059 7089 7119 1 Analog output 1 thr. 4 - Calibration point 6 input
-1 500 to +14 000 : %/100
Factory setting : 0
7030 7060 7090 7120 1 Analog output 1 thr. 4 - Calibration point 6 output
160 to 5 600 : mA/100 (4 – 20 mA) or mV (1 – 5 V)
Factory setting : 400 (4 – 20 mA) or 1 000 (1 – 5 V)
7031 7061 7091 7121 1 Analog output 1 thr. 4 - Calibration point 7 input
-1 500 to +14 000 : %/100
Factory setting : 0
7032 7062 7092 7122 1 Analog output 1 thr. 4 - Calibration point 7 output
160 to 5 600 : mA/100 (4 – 20 mA) or mV (1 – 5 V)
Factory setting : 400 (4 – 20 mA) or 1 000 (1 – 5 V)
7033 7063 7093 7123 1 Analog output 1 thr. 4 - Calibration point 8 input
-1 500 to +14 000 : %/100
Factory setting : 0
7034 7064 7094 7124 1 Analog output 1 thr. 4 - Calibration point 8 output
160 to 5 600 : mA/100 (4 – 20 mA) or mV (1 – 5 V)
Factory setting : 400 (4 – 20 mA) or 1 000 (1 – 5 V)
7035 7065 7095 7125 1 Analog output 1 thr. 4 - Calibration point 9 input
-1 500 to +14 000 : %/100
Factory setting : 0
7036 7066 7096 7126 1 Analog output 1 thr. 4 - Calibration point 9 output
160 to 5 600 : mA/100 (4 – 20 mA) or mV (1 – 5 V)
Factory setting : 400 (4 – 20 mA) or 1 000 (1 – 5 V)
(*) Factory setting
■ ANALOG OUTPUT TYPE
SET VALUE. ID PARAMETER
1 I Current
2 U Voltage
3 P Active power
4 Q Reactive power
5 S Apparent power
6 PF Power factor
7 F Frequency
8
9
10
I1
I2
I3
Current, Line 1
Current, Line 2
Current, Line 3
11 IN Neutral current
12
13
14
U12
U23
U31
Delta voltage, 1 – 2
Delta voltage, 2 – 3
Delta voltage, 3 – 1
15
16
17
U1N
U2N
U3N
Phase voltage, Phase 1
Phase voltage, Phase 2
Phase voltage, Phase 3
18
19
20
P1
P2
P3
Active power, Phase 1
Active power, Phase 2
Active power, Phase 3
21
22
23
Q1
Q2
Q3
Reactive power, Phase 1
Reactive power, Phase 2
Reactive power, Phase 3
24
25
26
S1
S2
S3
Apparent power, Phase 1
Apparent power, Phase 2
Apparent power, Phase 3
27
28
29
PF1
PF2
PF3
Power factor, Phase 1
Power factor, Phase 2
Power factor, Phase 3
