■ ENERGY
Writing the following registers enables energy presetting. Set Modbus Register Access in order to write in the energy and fractions.
ADDR. WORD ID PARAMETER UNIT
129 2 EP Active energy, high tariff, incoming kWh/10
131 2 EQ Reactive energy, high tariff, LAG kvarh/10
133 2 ES Apparent energy, high tariff kVAh/10
135 2 EP– Active energy, high tariff, outgoing kWh/10
137 2 EQ– Reactive energy, high tariff, LEAD kvarh/10
139
141
2
2
EQ+LAG
EQ+LEAD
Reactive energy, high tariff, incoming, LAG
Reactive energy, high tariff, incoming, LEAD
kvarh/10
kvarh/10
143
145
2
2
EQ–LAG
EQ–LEAD
Reactive energy, high tariff, outgoing, LAG
Reactive energy, high tariff, outgoing, LEAD
kvarh/10
kvarh/10
147 2 TIMER Energy count time, high tariff h/10
149
151
2
2
EQ+P
EQ–P
Reactive energy, high tariff, incoming 2.00
Reactive energy, high tariff, outgoing 2.00
kvarh/10
kvarh/10
153 2 EPA
Active energy, high tariff, (incoming – outgoing) 2.00 kWh/10
155 2 EQA
Reactive energy, high tariff, (incoming + outgoing) 2.00 kvarh/10
161 2 L-EP Active energy, low tariff, incoming kWh/10
163 2 L-EQ Reactive energy, low tariff, LAG kvarh/10
165 2 L-ES Apparent energy, low tariff kVAh/10
167 2 L-EP– Active energy, low tariff, outgoing kWh/10
169 2 L-EQ– Reactive energy, low tariff, LEAD kvarh/10
171
173
2
2
L-EQ+LAG
L-EQ+LEAD
Reactive energy, low tariff, incoming, LAG
Reactive energy, low tariff, incoming, LEAD
kvarh/10
kvarh/10
175
177
2
2
L-EQ–LAG
L-EQ–LEAD
Reactive energy, low tariff, outgoing, LAG
Reactive energy, low tariff, outgoing, LEAD
kvarh/10
kvarh/10
179 2 L-TIMER Energy count time, low tariff h/10
181
183
2
2
L-EQ+P
L-EQ–P
Reactive energy, low tariff, incoming 2.00
Reactive energy, low tariff, outgoing 2.00
kvarh/10
kvarh/10
185 2 L-EPA
Active energy, low tariff, (incoming – outgoing) 2.00 kWh/10
187 2 L-EQA
Reactive energy, low tariff, (incoming + outgoing) 2.00 kvarh/10
193 2 EP_L Active energy fraction, high tariff, incoming kWh/(10×2
32
)
195 2 EQ_L Reactive energy fraction, high tariff, LAG kvarh/(10×2
32
)
197 2 ES_L Apparent energy fraction, high tariff kVAh/(10×2
32
)
199 2 EP–_L Active energy fraction, high tariff, outgoing kWh/(10×2
32
)
201 2 EQ–_L Reactive energy fraction, high tariff, LEAD kvarh/(10×2
32
)
203
205
2
2
EQ+LAG_L
EQ+LEAD_L
Reactive energy fraction, high tariff, incoming, LAG
Reactive energy fraction, high tariff, incoming, LEAD
kvarh/(10×2
32
)
kvarh/(10×2
32
)
207
209
2
2
EQ–LAG_L
EQ–LEAD_L
Reactive energy fraction, high tariff, outgoing, LAG
Reactive energy fraction, high tariff, outgoing, LEAD
kvarh/(10×2
32
)
kvarh/(10×2
32
)
211 2 TIMER_L Energy fraction count time, high tariff seconds/1 000
213
215
2
2
EQ+P_L
EQ–P_L
Reactive energy fraction, high tariff, incoming 2.00
Reactive energy fraction, high tariff, outgoing 2.00
kvarh/(10×2
32
)
kvarh/(10×2
32
)
217 2 EPA_L
Active energy fraction, high tariff, (incoming – outgoing) 2.00 kWh/(10×2
32
)
219 2 EQA_L
Reactive energy fraction, high tariff, (incoming + outgoing) 2.00 kvarh/(10×2
32
)
225 2 L-EP_L Active energy fraction, low tariff, incoming kWh/(10×2
32
)
227 2 L-EQ_L Reactive energy fraction, low tariff, LAG kvarh/(10×2
32
)
229 2 L-ES_L Apparent energy fraction, low tariff kVAh/(10×2
32
)
231 2 L-EP–_L Active energy fraction, low tariff, outgoing kWh/(10×2
32
)
233 2 L-EQ–_L Reactive energy fraction, low tariff, LEAD kvarh/(10×2
32
)
235
237
2
2
L-EQ+LAG_L
L-EQ+LEAD_L
Reactive energy fraction, low tariff, incoming, LAG
Reactive energy fraction, low tariff, incoming, LEAD
kvarh/(10×2
32
)
kvarh/(10×2
32
)
239
241
2
2
L-EQ–LAG_L
L-EQ–LEAD_L
Reactive energy fraction, low tariff, outgoing, LAG
Reactive energy fraction, low tariff, outgoing, LEAD
kvarh/(10×2
32
)
kvarh/(10×2
32
)
243 2 L-TIMER_L Energy fraction count time, low tariff seconds/1 000
245
247
2
2
L-EQ+P_L
L-EQ–P_L
Reactive energy fraction, low tariff, incoming 2.00
Reactive energy fraction, low tariff, outgoing 2.00
kvarh/(10×2
32
)
kvarh/(10×2
32
)
249 2 L-EPA_L
Active energy fraction, low tariff, (incoming – outgoing) 2.00 kWh/(10×2
32
)
251 2 L-EQA_L
Reactive energy fraction, low tariff, (incoming + outgoing) 2.00 kvarh/(10×2
32
)
