■ AVERAGE VALUE
ADDR. WORD ID PARAMETER UNIT
257 2 I AVG Current AVG mA
259
261
263
2
2
2
I1 AVG
I2 AVG
I3 AVG
Current AVG, Line 1
Current AVG, Line 2
Current AVG, Line 3
mA
mA
mA
265 2 IN AVG Neutral current AVG mA
273 2 I AVG 1 Current AVG, History 1 mA
275
277
279
2
2
2
I1 AVG 1
I2 AVG 1
I3 AVG 1
Current AVG, Line 1, History 1
Current AVG, Line 2, History 1
Current AVG, Line 3, History 1
mA
mA
mA
281 2 IN AVG 1 Neutral current AVG, History 1 mA
289 2 I AVG 2 Current AVG, History 2 mA
291
293
295
2
2
2
I1 AVG 2
I2 AVG 2
I3 AVG 2
Current AVG, Line 1, History 2
Current AVG, Line 2, History 2
Current AVG, Line 3, History 2
mA
mA
mA
297 2 IN AVG 2 Neutral current AVG, History 2 mA
305 2 I AVG 3 Current AVG, History 3 mA
307
309
311
2
2
2
I1 AVG 3
I2 AVG 3
I3 AVG 3
Current AVG, Line 1, History 3
Current AVG, Line 2, History 3
Current AVG, Line 3, History 3
mA
mA
mA
313 2 IN AVG 3 Neutral current AVG, History 3 mA
321 2 I AVG 4 Current AVG, History 4 mA
323
325
327
2
2
2
I1 AVG 4
I2 AVG 4
I3 AVG 4
Current AVG, Line 1, History 4
Current AVG, Line 2, History 4
Current AVG, Line 3, History 4
mA
mA
mA
329 2 IN AVG 4 Neutral current AVG, History 4 mA
513
515
517
2
2
2
P AVG
Q AVG
S AVG
Active power AVG
Reactive power AVG
Apparent power AVG
W
var
VA
529
531
533
2
2
2
P AVG 1
Q AVG 1
S AVG 1
Active power AVG, History 1
Reactive power AVG, History 1
Apparent power AVG, History 1
W
var
VA
545
547
549
2
2
2
P AVG 2
Q AVG 2
S AVG 2
Active power AVG, History 2
Reactive power AVG, History 2
Apparent power AVG, History 2
W
var
VA
561
563
565
2
2
2
P AVG 3
Q AVG 3
S AVG 3
Active power AVG, History 3
Reactive power AVG, History 3
Apparent power AVG, History 3
W
var
VA
577
579
581
2
2
2
P AVG 4
Q AVG 4
S AVG 4
Active power AVG, History 4
Reactive power AVG, History 4
Apparent power AVG, History 4
W
var
VA
