■ MAXIMUM / MINIMUM VALUE
ADDR. WORD ID PARAMETER UNIT
769 2 I MAX Current MAX mA
771 2 U MAX Voltage MAX V/100
773 2 P MAX Active power MAX W
775 2 Q MAX Reactive power MAX var
777 2 S MAX Apparent power MAX VA
779 2 PF MAX Power factor MAX 1/10 000
781 2 F MAX Frequency MAX Hz/100
801
803
805
2
2
2
I1 MAX
I2 MAX
I3 MAX
Current MAX, Line 1
Current MAX, Line 2
Current MAX, Line 3
mA
mA
mA
807 2 IN MAX Neutral current MAX mA
809
811
813
2
2
2
U12 MAX
U23 MAX
U31 MAX
Delta voltage MAX, 1 – 2
Delta voltage MAX, 2 – 3
Delta voltage MAX, 3 – 1
V/100
V/100
V/100
815
817
819
2
2
2
U1N MAX
U2N MAX
U3N MAX
Phase voltage MAX, Phase 1
Phase voltage MAX, Phase 2
Phase voltage MAX, Phase 3
V/100
V/100
V/100
821
823
825
2
2
2
P1 MAX
P2 MAX
P3 MAX
Active power MAX, Phase 1
Active power MAX, Phase 2
Active power MAX, Phase 3
W
W
W
827
829
831
2
2
2
Q1 MAX
Q2 MAX
Q3 MAX
Reactive power MAX, Phase 1
Reactive power MAX, Phase 2
Reactive power MAX, Phase 3
var
var
var
833
835
837
2
2
2
S1 MAX
S2 MAX
S3 MAX
Apparent power MAX, Phase 1
Apparent power MAX, Phase 2
Apparent power MAX, Phase 3
VA
VA
VA
839
841
843
2
2
2
PF1 MAX
PF2 MAX
PF3 MAX
Power factor MAX, Phase 1
Power factor MAX, Phase 2
Power factor MAX, Phase 3
1/10 000
1/10 000
1/10 000
865
867
869
2
2
2
THD I1 MAX
THD I2 MAX
THD I3 MAX
Current total harmonic distortion MAX, Line 1
Current total harmonic distortion MAX, Line 2
Current total harmonic distortion MAX, Line 3
%/10
%/10
%/10
871 2 THD IN MAX Neutral current total harmonic distortion MAX %/10
873
875
877
2
2
2
THD U12 MAX
THD U23 MAX
THD U31 MAX
Delta voltage total harmonic distortion MAX, 1 – 2
Delta voltage total harmonic distortion MAX, 2 – 3
Delta voltage total harmonic distortion MAX, 3 – 1
%/10
%/10
%/10
879
881
883
2
2
2
THD U1N MAX
THD U2N MAX
THD U3N MAX
Phase voltage total harmonic distortion MAX, Phase 1
Phase voltage total harmonic distortion MAX, Phase 2
Phase voltage total harmonic distortion MAX, Phase 3
%/10
%/10
%/10
897 2 I MAX AVG Current MAX AVG mA
899
901
903
2
2
2
I1 MAX AVG
I2 MAX AVG
I3 MAX AVG
Current MAX AVG, Line 1
Current MAX AVG, Line 2
Current MAX AVG, Line 3
mA
mA
mA
905 2 IN MAX AVG Neutral current MAX AVG mA
907
909
2
2
P MAX AVG+
P MAX AVG–
Active power MAX AVG, incoming
Active power MAX AVG, outgoing
W
W
911
913
2
2
Q MAX AVG+
Q MAX AVG–
Reactive power MAX AVG, incoming
Reactive power MAX AVG, outgoing
var
var
915 2 S MAX AVG Apparent power MAX AVG VA
929 2 I MIN Current MIN mA
931 2 U MIN Voltage MIN V/100
933 2 P MIN Active power MIN W
935 2 Q MIN Reactive power MIN var
937 2 S MIN Apparent power MIN VA
939 2 PF MIN Power factor MIN 1/10 000
941 2 F MIN Frequency MIN Hz/100
