M-system 53U - Page 32

53U
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
EM-6485-B Rev.21 P. 32 / 52
ADDR. WORD ID PARAMETER UNIT
961
963
965
2
2
2
I1 MIN
I2 MIN
I3 MIN
Current MIN, Line 1
Current MIN, Line 2
Current MIN, Line 3
mA
mA
mA
967 2 IN MIN Neutral current MIN mA
969
971
973
2
2
2
U12 MIN
U23 MIN
U31 MIN
Delta voltage MIN, 1 – 2
Delta voltage MIN, 2 – 3
Delta voltage MIN, 3 – 1
V/100
V/100
V/100
975
977
979
2
2
2
U1N MIN
U2N MIN
U3N MIN
Phase voltage MIN, Phase 1
Phase voltage MIN, Phase 2
Phase voltage MIN, Phase 3
V/100
V/100
V/100
981
983
985
2
2
2
P1 MIN
P2 MIN
P3 MIN
Active power MIN, Phase 1
Active power MIN, Phase 2
Active power MIN, Phase 3
W
W
W
987
989
991
2
2
2
Q1 MIN
Q2 MIN
Q3 MIN
Reactive power MIN, Phase 1
Reactive power MIN, Phase 2
Reactive power MIN, Phase 3
var
var
var
993
995
997
2
2
2
S1 MIN
S2 MIN
S3 MIN
Apparent power MIN, Phase 1
Apparent power MIN, Phase 2
Apparent power MIN, Phase 3
VA
VA
VA
999
1001
1003
2
2
2
PF1 MIN
PF2 MIN
PF3 MIN
Power factor MIN, Phase 1
Power factor MIN, Phase 2
Power factor MIN, Phase 3
1/10 000
1/10 000
1/10 000
■ TOTAL HARMONIC DISTORTION (THD)
ADDR. WORD ID PARAMETER UNIT
1281 2 THD I1 Current total harmonic distortion, Line 1 %/10
1283 2 THD I2 Current total harmonic distortion, Line 2 %/10
1285 2 THD I3 Current total harmonic distortion, Line 3 %/10
1287 2 THD IN Neutral current total harmonic distortion %/10
1289 2 THD U12 Delta voltage total harmonic distortion, 1 – 2 %/10
1291 2 THD U23 Delta voltage total harmonic distortion, 2 – 3 %/10
1293 2 THD U31 Delta voltage total harmonic distortion, 3 – 1 %/10
1295 2 THD U1N Phase voltage total harmonic distortion, Phase 1 %/10
1297 2 THD U2N Phase voltage total harmonic distortion, Phase 2 %/10
1299 2 THD U3N Phase voltage total harmonic distortion, Phase 3 %/10
