Change Setting
(SETTINGS)
Demand Setting
(DEMAND)
Energy Setting
(ENERGY)
Average current
(I)
DIN : External contact input
1 thr. 60 : Minutes (30)
Average power
(POWER)
DIN : External contact input
1 thr. 60 : Minutes (30)
Pulse output 1
(COUNT1)
*4
Pulse weight 1
(WEIGHT1)
0.1 thr. 10 000.0 :
kWh / kvarh / kVAh (1.0)
Pulse width 1
(DURATION1)
100 thr. 2 000 ms (100 ms increments)
(100)
Tariff switching
(TARIFF)
DISABLE (*)
ENABLE
*3. 0.1 ≤T1.5 timer length < T3.5 timer length ≤ 6.0
*4. Refer to Modbus - Setting – Energy setting – Energy count type, for selectable options.
Pulse output 2
(COUNT2)
*4
Pulse weight 2
(WEIGHT2)
0.1 thr. 10 000.0 :
kWh / kvarh / kVAh (1.0)
Pulse width 2
(DURATION2)
100 thr. 2 000 ms (100 ms increments)
(100)
Pulse output 3
(COUNT3)
*4
Pulse weight 3
(WEIGHT3)
0.1 thr. 10 000.0 :
kWh / kvarh / kVAh (1.0)
Pulse width 3
(DURATION3)
100 thr. 2 000 ms (100 ms increments)
(100)
Pulse output 4
(COUNT4)
*4
Pulse weight 4
(WEIGHT4)
0.1 thr. 10 000.0 :
kWh / kvarh / kVAh (1.0)
Pulse width 4
(DURATION4)
100 thr. 2 000 ms (100 ms increments)
(100)
(*) or ( ) : Factory setting
Modbus setting
(MODBUS)
Modbus address
(ADDRESS)
1 thr. 247 (1)
Baud rate
(BAUDRATE)
1200 bps
2400 bps
4800 bps
9600 bps
19200 bps
38400 bps (*)
Parity type
(PARITY)
NONE
ODD (*)
EVEN
Stop bit length
(STOP BIT)
1 (*)
2
T1.5 timer length
(T1.5)
0.1 thr. 5.9 (1.5) *
3
T3.5 timer length
(T3.5)
0.2 thr. 6.0 (3.5) *
3
NORMAL : Low bit address (word) (*)
SWAP : High bit address (word)
Long register
(LONG REG)
DO
