Analog Output
Setting (AOUT)
Change Setting
(SETTINGS)
Assigned measurand
(INPUT)
*5
CH1
CH2
CH3
CH4
Fine adjustments
(ADJUST)
Zero adjustment
(ZERO)
Discrete I/O
Setting (DIO)
Discrete output 1 function
(DO1-FUNC)
NO FUNC : Not used (*)
ENERGY : Energy count pulse
ALARM : Alarm output
Discrete output 1 mode
(DO1-TYPE)
N-O : Normally open contact (*)
N-C : Normally closed contact
Discrete output 2 function
(DO2-FUNC)
NO FUNC : Not used (*)
ENERGY : Energy count pulse
ALARM : Alarm output
Discrete output 2 mode
(DO2-TYPE)
N-O : Normally open contact (*)
N-C : Normally closed contact
Discrete output 3 function
(DO3-FUNC)
NO FUNC : Not used (*)
ENERGY : Energy count pulse
ALARM : Alarm output
Discrete output 3 mode
(DO3-TYPE)
N-O : Normally open contact (*)
N-C : Normally closed contact
Discrete output 4 function
(DO4-FUNC)
NO FUNC : Not used (*)
ENERGY : Energy count pulse
ALARM : Alarm output
Discrete output 4 mode
(DO4-TYPE)
N-O : Normally open contact (*)
N-C : Normally closed contact
Discrete input function
(DIN-FUNC)
NO FUNC : Not used (*)
DEMAND : Update demand
RESET E : Reset energy
CLR ALARM : Reset alarm
TARIFF : Switch tariff
Discrete input type
(DIN-TYPE)
N-O : Normally open contact (*)
N-C : Normally closed contact
*5. Refer to “PARAMETERS TO BE ASSIGNED ANALOG OUTPUS.”
*6. 0.4 to 5.6V for voltage output.
Linearization
(LINEARIZE)
Prorportional output
(LINEAR)
Span adjustment
(SPAN)
-5.00 to +5.00%
(0.00)
95.00 to 105.00%
(100.00)
LINEAR : Proportional (*)
TABLE : Linearized
Input 0%
(IN0P)
-15.00 to +140.00%
(0.00)
1.6 to 22.4mA
(4.0) *
6
Output 0%
(OUT0P)
Input 100%
(IN100P)
-15.00 to +140.00%
(100.00)
1.6 to 22.4mA
(20.0) *
6
Output 100%
(OUT100P)
Linearized output
(TABLE)
Calibration point 0
input (IN0)
-15.00 to +140.00%
(0.00)
1.6 to 22.4mA
(4.0) *
6
Calibration point 0
output (OUT0)
Calibration point 9
input (IN9)
-15.00 to +140.00%
(100.00)
1.6 to 22.4mA
(4.0) *
6
Calibration point 9
output (OUT9)
(*) or ( ) : Factory setting
