MacAllister MTC500 - Your product

MTC500 by MacAllister
Getting started...
03
Your product
Your product
1. 45° Vertical fence
2. Transportation handle
3. Upper protective guard
4. Working table
5. Scale
6. Lower protective guard
7. On/Off switch
8. Locking knob
(for parallel cutting guide)
9. Water reservoir plug
10. Base foot
11. Plug cable
12. Parallel cutting guide
13. Mitre cutting guide
14. Locking knob
(for mitre cutting guide)
15. Cutting disc
16. Metal bracket
17. Locking knob
(for upper protective guard)
3
2
5
6
1
13
12
15
16
17
14
10
11
9
78
4
EN
