Fig. 21
WARNING: Risk of injury!
Never use segmented cutting discs.
WARNING: Risk of injury!
Always wear protective gloves when replacing the cutting disc.
WARNING: Risk of injury!
The metal bracket must always be aligned parallel to the cutting
disc.
28
MTC500 by MacAllister
Care and maintenance
In more detail…
> Raise the 45° vertical fence (1) approx. 45° and remove.
> Place a suitable collector below the product's drain opening.
> Remove water reservoir plug (9) and drain off all the dirty cooling water.
> Filling the product with water (Refer to “Filling the product with water” section
on Page. 19-20).
Replacing the cutting disc
Removing the cutting disc：
> Raise the vertical fence (1) approx. 45° and remove.
1
