Form # 46620 Issue 11/06
58
MAINTENANCE/SERVICE
HAY CONDITIONER
Hay Conditioner Gear Case Lubricant
Check gear case lubricant level before first
operation and every 100 hours thereafter.
To check:
1. With gear case approximately level, remove
level plug (A).
2. Remove fill plug with breather (B).
3. Fill to level plughole. See "Recommended
Lubricants" for specified gear lube and capacity
of case.
4. Replace both plugs.
CHECK GEAR CASE LUBRICANT LEVEL
B
A
