OPERATOR'S STATION
Symbol Definitions
The following symbols are used to depict functions or reactions at the various instruments and controls. Learn
the meaning of these symbols before operating the Windrower.
- Engine oil pressure
- Transmission oil pressure
- Parking brake on
- Engine hours
- Header hours
- Fuel
- Area cut per hou
r
- Voltage
- Area cut: subtotal
Area cut:
g
rand total
- Flashing amber lights
- Head lights
- Work (field) lights
- Turn signals
- Temperature control: heate
r
- Engine R.P.M.
- Temperature control:
Air conditioning
- Turn to increase output:
Heater or air conditioner
- Engine coolant temperature
- Blowe
r
- Windshield wipe
r
- Engine throttle
- Forward ground speed
- Reverse ground speed
-Fast
-Slow
- Neutral
- Reel speed
