Form # 46584 Issue 11/06 Web Rev_01
68
MAINTENANCE/SERVICE
Diesel Engine
ENGINE SPEED (continued):
TURBO ENGINE
THROTTLE ROD ADJUSTMENT
Throttle lever in cab should move fuel pump lever
the full range between slow speed stop and full
RPM stop without contacting the console at either
end. To adjust, reposition cable anchor in slots (C).
NOTE: In addition to in-cab tachometer, hand held
tach can be attached at bevel gear box output
shaft. For access to end of shaft, remove cover (D)
on right side of tractor frame.
VALVE TAPPET CLEARANCE
Every 1000
hours of operation, have diesel engine
valve tappet clearance checked and adjusted by
your Windrower dealer.
GENERAL ENGINE INSPECTION
Every 2000
hours of operation, see your
Windrower dealer for required general service or
tune-up.
For diesel engine, have fuel injection pump and
nozzles inspected at this time.
C
THROTTLE ROD ADJUSTMENT - TURBO
D
ACCESS TO GEARBOX SHAFT
FOR TACHOMETER
