DLM8/12 Loudspeaker: Rear Panel Features
1. Power Connection
Thisisastandard3-prongIECpowerconnector.
Connectthedetachablepowercord(includedin 
thepackagingwiththeloudspeaker)tothepower
receptacle,andplugtheotherendofthepower 
cordintoanACoutlet.
MakesurethattheACpowerismatchedto
theACpowerindicatedontherearpanel
(totheleftoftheIECreceptacle).
Disconnectingtheplug’sgroundpinis
dangerous.Don’tdoit!
2. Power Switch
Pressthetopofthisrockerswitchinwardstoturnon
theloudspeaker.ThefrontpanelpowerLEDwillglow
withhappiness...oratleastitwilliftheloudspeakeris
pluggedintoasuitableliveACmainssupply.
Pressthebottomofthisrockerswitchinwardstoturn
offtheloudspeaker.
Asageneralguide,DLMloudspeakersshould
beturnedonlast,afteranymixerorother
signalsource.Assuch,theyshouldalsobe
turnedoffrst.Thiswillreducethepossibilityofany
turn-onorturn-offthumpsandothernoisesgenerated
byanyupstreamequipmentfromcomingoutofthe
speakers.
