Mackie DRM12A - Table of Contents; Contents; Features

Owner’s Manual
3
Owner’s Manual
Contents Features
Part No. SW267 Rev. A 0/9
©2019 LOUD Audio, LLC. All Rights Reserved.
• High-eciency 2000W Class-D amplifier oers ample
headroom for professional applications
o Universal power supply (00-240 VAC) with Power Factor
Correction technology ensures consistent performance
even with unstable AC power
o Next-gen protection circuitry keeps transducers safe
and ensures peak performance in all applications
• Advanced Impulse™ DSP module
o Precision crossovers and transducer time-alignment
deliver reference quality sound that is consistent
throughout the frequency range
o Cutting-edge FIR Filtering technology drastically reduces
inherent anomalies, phase issues, and muddy midrange
resulting in crystal clear sound
• DRM Control Dashboard™ features a high-contrast full
color display for easy single-knob access to configuration,
processing, and more
o View current EQ and voicing mode, high-resolution
metering, and more from a single overview window
o Preset array configuration settings make setup easy
with modes for  cabinet, 2 cabinets, 3-4 cabinets
with long throw option, and independent Sub option
w/ variable crossover
o Adjustable 3-band parametric EQ allows for additional
customization and tuning for your application and venue
o Alignment Delay control for delay stacks
o Save and recall up to 6 user presets for various
applications and venues
o Screensaver plus dimmer and contrast control
o System lock with 4-digit passcode
• Parallel XLR Input and Output
• Premium components and cabinet design
o Road-worthy 5mm plywood construction and internal
bracing oers optimal acoustic performance with
a touring-grade textured coating and powder-coated
heavy gauge steel grille
o Unique ported design provides exceptionally smooth
yet punchy low frequency response while providing cool
air to the internal amplifier
o Triple " Titanium diaphragm compression driver array
is perfectly matched to the amplifier for maximum
clarity and eciency
o 2" high-excursion woofer oers minimal distortion
with increased bass response and reliability to withstand
the most demanding live applications
• Versatile configuration options
o Dual-angle pole mount
o Flyable with up to 4 DRM2A cabinets and 2 DRM8S
subwoofers using the FB00 Fly Bar
o 7 x M0 flypoints
o Integrated flying hardware
o Optional FB00 Fly Bar
• Max SPL: 35 dB
• Coverage: 20˚V x 0˚H
• 55.0 lb / 24.9 kg
Like us
Follow us
Watch our dang videos
Important Safety Instructions ........................................... 2
Contents / Features ............................................................ 3
Introduction ........................................................................ 4
Getting Started ................................................................... 5
Hookup Diagrams ............................................................... 6
DRM2A Loudspeaker: Rear Panel Features ...................3
. AC In Jack ...............................................................3
2. AC Thru Jack ..........................................................3
3. AC Thru Circuit Breaker .........................................3
4. XLR Input ................................................................4
5. XLR Output .............................................................4
6. LCD Display ............................................................4
7. Speaker Control Knob ............................................4
8 and 9. Dual-Angle Pole Cup .................................... 4
DRM Control Dashboard™ ................................................5
Main ............................................................................. 5
Array Mode..................................................................6
Sub ..............................................................................6
EQ Setup ......................................................................7
Delay ............................................................................8
Configuration ..............................................................9
Array Usage .......................................................................22
Floor Mounting .......................................................... 22
Protection Circuitry ..........................................................23
Limiting ......................................................................23
Overexcursion Protection .........................................23
Thermal Protection ...................................................23
AC Power ........................................................................... 23
Care and Maintenance .....................................................23
Rigging ............................................................................. 24
Room Acoustics ................................................................26
Appendix A: Service Information ..................................... 27
Appendix B: Technical Information .................................28
DRM2A Dimensions .................................................29
DRM2A Block Diagram ............................................ 30
Limited Warranty ...............................................................3
