H U I R E F E R E N C E G U I D E
Function Transmitted Recognized Remarks
Basic Channel Default 1 1 Channel 1 only
Changed
Mode Default X X Not Applicable
Messages X X
Altered X X
Note O X 90 00 7F Echoed - sent and received
Number True Voice X O 90 00 00 “active sensing” only
Velocity Note ON X X
Note OFF
Aftertouch Keys X O meters
Channels X X
Pitch Bend X X
Control Change 00-07 Faders 0C (2C) LEDs Fixed specification
(20-27) Servo Faders Fader resolution
08-0B Ctrl Pots Relays (00-07 MSB)
0D Jog wheel Clicker (20-27 LSB)
0F (2F) Switches Tone
40-4C V-Pots Touch Off
Program
Change true number X X
System Exclusive X O Character displays, System Parameters
System Common Song Pos X X
Song Sel X X
Tune X X
System Clock (F8) X O Increment frames display (+1)
Real-time Commands X X
MTC X O MTC 1/4 frame
Local On/Off X X
Aux All Notes Off X X
Messages
Active Sensing X * * see Note Number above
System Reset X X
Mode 1: Omni On, Poly Mode 2: Omni On, Mono O: Yes
Mode 3: Omni Off, Poly Mode 4: Omni Off, Mono X: No
HUI MIDI Implementation Chart Version: 1.0 Date: 9/19/97
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
RXD
TXD
GND
RXD
TXD
GND
DB9
FEMALE
DB9
FEMALE
TO
COMPUTER
RS-232 PORT
(May require an
adapter to match
connector on your
computer)
TO
HUI
SERIAL PORT
STANDARD DB9
COMPUTER CABLE
See page 19 for more pin configuration
information.
SPECIFICATIONS
RS-232 Connection Diagram
SPECIFICATIONS
