6. On page 51:
In the MIDI SYSEX MESSAGE NUMBERS chart, message 44h is ignored by the console. System status is a
“request-only” message (04h), and cannot be written to the console with a sysex message.
The DATA Structure for Sysex dumps is as follows (this replaces the DATA Structure chart shown on page 51):
3
DATA Structure: SR40•8 = 18 bytes, nibblized low-high.
0 = Mute OFF; 1 = Mute ON.
{[0000 N1] [0000 N2] [0000 N3] ... [0000 N18]}
N1 = Channels 1-4 [4 3 2 1]
N2 = Channels 5-8 [8 7 6 5]
N3 = Channels 9-12 [12 11 10 9]
N4 = Channels 13-16 [16 15 14 13]
N5 = Channels 17-20 [20 19 18 17]
N6 = Channels 21-24 [24 23 22 21]
N7 = AUX RETURN A1-A4 [A4 A3 A2 A1]
N8 = Not Used [— — — —]
N9 = Channels 25-28 [28 27 26 25]
N10 = Channels 29-32 [32 31 30 29]
N11 = Channels 33-36 [36 35 34 33]
N12 = Channels 37-40 [40 39 38 37]
N13 = AUX SEND 1-4 [4 3 2 1]
N14 = AUX SEND 5-8 [8 7 6 5]
N15 = SUB 1-4 [4 3 2 1]
N16 = SUB 5-8 [8 7 6 5]
N17 = MATRIX A-D [D C B A]
N18 = Not Used [— — — —]
3
DATA Structure: SR56•8 = 22 bytes, nibblized low-high.
0 = Mute OFF; 1 = Mute ON.
{[0000 N1] [0000 N2] [0000 N3] ... [0000 N22]}
N1 = Channels 1-4 [4 3 2 1]
N2 = Channels 5-8 [8 7 6 5]
N3 = Channels 9-12 [12 11 10 9]
N4 = Channels 13-16 [16 15 14 13]
N5 = Channels 17-20 [20 19 18 17]
N6 = Channels 21-24 [24 23 22 21]
N7 = Channels 25-28 [28 27 26 25]
N8 = Channels 29-32 [32 31 30 29]
N9 = Channels 33-36 [36 35 34 33]
N10 = Channels 37-40 [40 39 38 37]
N11 = AUX RETURN A1-A4 [A4 A3 A2 A1]
N12 = Not Used [— — — —]
N13 = Channels 41-44 [44 43 42 41]
N14 = Channels 45-48 [48 47 46 45]
N15 = Channels 49-52 [52 51 50 49]
N16 = Channels 53-56 [56 55 54 53]
N17 = AUX SEND 1-4 [4 3 2 1]
N18 = AUX SEND 5-8 [8 7 6 5]
N19 = SUB 1-4 [4 3 2 1]
N20 = SUB 5-8 [8 7 6 5]
N21 = MATRIX A-D [D C B A]
N22 = Not Used [— — — —]
7. On page 53:
In the MIDI IMPLEMENTATION CHART, the remark for the Note Number function should read: “See
Table
163 on page 54.”
The remark for the Velocity function should read: “See
Table 163 on page 54.”
The remark for the System Exclusive function should read: “See MIDI Sysex Detail on
pages 50-51.”
