Page 16 of 31
Output Type “T” High Temperature SPECIFICATIONS & WIRING
SENSOR TYPE OMNI POLAR NPN with internal 3 k-Ohm pull-up resistor
SPECIFICATIONS
Construction Stainless Steel Housing (Barrel)
Connector Cable Length 2 meters
Operating Voltage 4.5 to 30V DC
Maximum Supply Current 18mA
Temperature Range
-40 - 150°C
-40 - 302°F
Illustration
Sensor fitted to meter
Illustration
Cable Connector
