Macnaught MX Series - Wetted Parts Material Guide

Page 22 of 31
Category
“P”
MX06P MX09P - MX12P MX19P - MX50P MX75P - MX100P
METER BODY SS 316 SS 316 SS 316
*
METER CAP SS 316 SS 316 SS 316
*
ROTORS
SS 316 / PPS** SS 316 / PPS** SS 316 / PPS / PEEK** *
HV ROTORS -
SS 316 / PPS** SS 316 / PPS** *
ROTOR SHAFTS SS 316 SS 316 SS 316
*
ROTOR BUSHES CARBON CARBON CARBON
*
O-RINGS FEP FEP
*
FEP
WETTED PARTS
Category
“F”
MX06F MX09F - MX12F MX19F - MX50F MX75F - MX100F
METER BODY AL AL AL AL
METER CAP AL AL AL AL
ROTORS PPS PPS PPS/PEEK** AL
HV ROTORS - PPS PPS AL
ROTOR SHAFTS SS 316 SS 316 SS 316 SS 316
ROTOR BUSHES - - - CARBON
O-RINGS FKM FKM FKM FKM
FEP - PTFE Encapsulated
SS 316 - Stainless Steel 316
AL - Aluminium Alloy
FKM - Viton ®
PPS - Polyphenylene Sulphide (PPS Resin)
PEEK - Polyether ether ketone
* Currently Unavailable
** SS 316 rotors are assembled with carbon bushes.
PPS and PEEK rotors do not have carbon bushes.
Category
“S”
MX06S MX09S - MX12S MX19S - MX25S MX40S - MX50S MX40S - MX100S
METER BODY AL AL AL AL AL
METER CAP AL AL AL AL AL
ROTORS SS 316 SS 316
SS 316/PEEK ** AL / PEEK **
AL
HVROTORS - SS 316 SS 316 AL AL
ROTOR SHAFTS SS 316 SS 316 SS 316 SS 316 SS 316
ROTOR BUSHES CARBON CARBON CARBON CARBON CARBON
O-RINGS FEP FEP FEP FEP FEP
