II
CONNECTIONS / ANSCHLUSSE / CONNEXIONES /
COLLEGAMENTI / CONEXIONES
ChecK Control
Fuse
25A 25A
Power Connector
+ Batt GND Remote
11 12 13 14 15 16
1 2 3 4 5 6 978 10
2 Ch 4Ch
Input
Mode
Gain
Control
4V 0,2V
L
R
Input
L
R
Input
Flat HI LOW
Filter
Mode
Flat HI LOW
Filter
Mode
2Ch 3Ch 4Ch
Output
Mode
Filter
Control
30Hz 600Hz
Filter
Control
30Hz 600Hz
Gain
Control
4V 0,2V
RearFront
O/M 44.50 26/06/02 9:48 Page 3
