TECHNICAL DATA
RMS Power:
IHF 202 480 Watt
Front/Rear @ 1 kHz < 0.08% THD at 4 Ohm 4 x 50 Watt
Front/Rear @ 1 kHz < 0.5% THD at 2 Ohm 4 x 100 Watt
Front/Rear @ 1 kHz < 0.5% THD mono at 4 Ohm 2 x 150 Watt
High-Pass, Front and Rear (30-600) Hz
Low Pass, Front and Rear (30-600) Hz
Crossover slope 12 dB/Octave
Frequency response ± 1 dB 10 - 50,000 Hz
Total harmonic distortion 0.08%
S/N (signal-to-noise ratio) IHFA-weighed >100 dB
Input sensitivity/impedance 200-4000 mV/22 kOhm
Speaker impedance
stereo 1 Ohm min
mono 2 Ohm min
Power supply 14.4 V DC (11-16 V allowed)
Weight 2.7 Kg
Size 217(l) x 49(h) x 280(d) mm
Due to continuing improvement, the features and the design are subject to change without
notice.
