TECHNICAL DATA
DIMENSIONS (STANDARD MODEL)
Operating Manual MT 25 / 30 YT 135
Fig. 115: Dimensions of the MT 25
Dimensions depending on tyres
Values A - D may be reduced by 50 mm at lowered rear
axles air suspension.
Tyres 10R20&
11R22,5
11R20&
12R22,5
315/60R22,5
A 925 mm 940 mm 880 mm
B 1060 mm 1075 mm 1015 mm
C 1590 mm 1605 mm 1545 mm
D 2025 mm 2024 mm 1980 mm
E 3200 mm 3215 mm 3155 mm
