MAFI MT 30 - Dimensions (Standard Model)

TECHNICAL DATA
DIMENSIONS (STANDARD MODEL)
134 Operating Manual MT 25 / 30 YT
Dimensions (standard model)
Fig. 114: Dimensions of the MT 25
Dimensions depending on wheel base
Wheel base Standard Extended
WB 3000 mm 3500 mm
L 5372 mm 5872 mm
RT 2020 mm 2520 mm
RS 2080 mm 2580 mm
