OPERATION
INSTRUMENT PANEL
Operating Manual MT 25 / 30 YT 63
Air-cushioned rear axle
Fig. 49: Bellows
You can lower the vehicle frame in order to take up parked low
trailers. Lowering is done by letting out the air of the air sus-
pension bellows of the rear axle.
Lowering the vehicle frame
Fig. 50: Air suspension button
X
Press the button and hold it down.
3 The vehicle frame is lowered.
After releasing the button the air suspension bellows are
inflated again and the vehicle frame is raised again to the
normal level.
Joystick for fifth wheel
Fig. 51: Joystick for fifth wheel
1 Joystick
2 Button
3 Lowering
4 Lifting
You can lift and lower the fifth wheel using the joystick.
The button 2 of the joystick has no function in the standard
model.
Lowering
X Press the joystick in the direction of the arrow 3.
3 The fifth wheel coupling is lowered.
Lifting
X Press the joystick in the direction of the arrow 4.
3 The fifth wheel coupling is lifted.
