OPERATION
MULTI-FUNCTION DISPLAY
Operating Manual MT 25 / 30 YT 79
Control indicators
Fig. 71: Control indicators
1 High beam headlamp
2 Parking brake
3 Turn indicators, vehicle
4 Turn indicators, trailer
5 Headlight
6 Battery charge control
The control indicators inform about the status of certain
controls.
Warning indicators
Fig. 72: Warning indicators
1 Malfunction, air reserve pressure (combo message circuit 1 to 3)
2 Transmission fault
3 Motor malfunction
4 Intake air filter blockage
The warning indicators notify you about conditions that should
not be ignored, otherwise damage to the MT can be done.
Information on cause and repair can be found in chapter
“SELF-HELP” under “Indicators on the multi-function display”
on page 125.
