CONTROL ELEMENTS
Instrument panel
Operating manual MT 32 / 36 73
L F Emergency gear, forward
L R Emergency gear, reverse
F No gear Clutch locked
R No gear Clutch locked
F Flashing; forward driving
direction selected, turbine
speed too high.
Caution! Gear engages when
turbine speed lowers.
R Flashing; reverse driving
direction selected, turbine
speed too high.
Caution! Gear engages when
turbine speed lowers.
N N Not neutral; waits for neutral
after start or serious error.
To engage a gear, first move
the shift lever to neutral and
then to the forward or reverse
position.
* * Oil temperature too low,
no gear available.
Let the engine/transmission
heat up.
* N Oil temperature low,
only one gear available.
Let the engine/transmission
heat up.
Bar display Explanation Remark
1 bar Manual mode; 1st gear Option
2 bars Manual mode; 2nd gear Option
3 bars Manual mode; 3rd gear Option
4 bars Manual mode; 4th, 5th, 6th gear Option
4 bars and 2 arrows Automatic mode
Bars flashing Torque converter clutch open
Spanner At least one error active
Table 2: Display messages during driving mode (symbols)
Display Warning Remark
W S Temperature of oil sump
W R Temperature of the retarder
W T Temperature of the torque converter
W E High engine speed (input speed)
W V High speed (output speed)
Table 3: Display messages during driving mode (warnings)
Display Explanation Remark
Table 1: Display messages during driving mode
