2-8 Radio Disassembly – Detailed
12. Slide the battery latch shaft out from the latch.
13. Unscrew the speaker bracket from the housing (see “Figure 2-6”).
14. Remove the speaker from on top of the speaker felt.
15. Remove the speaker felt from the grille area.
Figure 2-5
NOTE
Proceed to perform steps 13, 14, and 15 only if there is a need to replace the speaker,
speaker bracket or speaker felt.
Figure 2-6
