the switch is off.
Failover: turn on to protect your NDI transmission from failure. If the initial
source video fails, the backup device begins to provide a service. The initial
source will be automatically switched back to after it recovers. This function
is disabled by default.
■
Source name shows the backup NDI channel name.
Click Change... and select the failover (backup) video device within the
same NDI group as the initial source.
■
IP Address shows the IP Address of the backup NDI channel which is
automatically obtained after you select the backup NDI source.
■
Receiver Control: turn on Web control to enable you to open the Web UI
by clicking the gear icon in the NDI Studio Monitor application.
■
Only 1 NDI streaming session can be started each time, but you can add
multiple servers to the streaming server list.
■
When live streaming to NDI server, the encoder would send the main and
sub streams simultaneously.
■
You can push NDI over sub stream at the following encode profile:
■
Resolutions: 640x480, 640x360
■
Frame rate: 60, 59.94, 50, 30, 29.97, 25, 24, 15, 10, 5fps. To ensure
smooth viewing experience, the frame rate above 29.97fps is
recommended.
■
Max bitrate: 2 Mbps
■
