7. TECHNICAL DATA
6. INDIVIDUAL PROTECTION DEVICES AND RESIDUAL RISKS
Despite all adopted safety protection devices, following situations may be dangerous:
- fall or throw of wood sliver during working operation
- entangling parts of clothes in moving parts of the machine
- danger of fire
- danger of electrocution
- danger of damage due to noise emission
- danger of damage due to dust emission
To prevent risks during placing, installation, adjustment, use, ordinary and extraordinary maintenance, we
strictly recommend to use the following individual protection devices:
- gloves (for example during machine parts handling)
- anti-crushing and anti-sliding shoes
- glasses or face-shields against chip or wood sliver during working or cleaning operation of the machine
- anti-dust masks
Moreover, the clothes must be suited to avoid danger of:
- catching
- dragging
- crushing
- sliding
- abrasion
- contact lenses are prohibited
For further information and recommendation please refer to chapter. OP-
Technical feature BS 35
N°. OF SPINDLES
35
INTERAXIS BETWEEN SPINDLES
32 mm
INTERAXIS BETWEEN FIRST AND LAST SPINDLES
1088 mm
MAX. BORING DEPTH
85 mm
MAX DIMENSION OF THE WORKING PIECE
1340 x 3000 mm
HEIGHT OF THE WORKING TABLE
875 mm
N° OF CLAMPS
2
STANDARD PNEUMATIC PRESSURE
6 - 8 Bar
STANDARD AIR CONSUMPTION FOR WORKING CYCLE
15 L / Cycle
N° OF MOTORS
2
MOTOR POWER
2 (1,5) HP( KW )
MOTOR r.p.m.
2800 RPM
MACHINE DIMENSIONS ( B x L x H )
990x1670x1280
mm
NET WEIGHT
375 Kg
DIMENSION OF THE WORKING TABLE
1330 x 410 mm
Never leave the machine unattended when con-
nected to the electrical power supply
