POS. CODE DENOMINATION GROUP REFERENCE SHEET
1 26354000 FRAME UNIT SHEET. 1
2 26354100 TABLE UNIT SHEET. 2
3 26300200 RACK UNIT SHEET. 3
4 26054300 LH SQUARE UNIT SHEET. 4
5 26054301 RH SQUARE UNIT SHEET. 4
6 26354401 SPINDLE HEAD UNIT SHEET. 5
7 26300500 CLAMPING UNIT SHEET. 6
8 26054502 CLAMP UNIT ( CLAMPING UNIT SUBGROUP ) SHEET. 7
9 26354600 BACK STOP UNIT SHEET. 8
10 26300700 HEAD UNIT SHEET. 9
11 26054810 1,5 +1,5 Mt EXTENSION FENCE + N° 4 ROTARY STOPS UNIT SHEET. 10
12 26050801 SWIVEL STOP UNIT ( EXTENSION FENCE SUBGROUP ) SHEET. 11
# # PNEUMATIC SYSTEM SHEET. 12-13
# # ELECTRIC SYSTEM SHEET. 14-15
25. SPARE PARTS CATALOGUE
