The packaging contains also the shoulders, clamping unit, back stop unit and a cardboard box with some other
accessories inside, as shownin the figure below.
The box contains the following accessories:
• Boring System user and maintenance manual
• Wrenches Kit
• n°2 clamps
• Lh square unit
• Rh square unit
Remove the two fixing devices, which lock the machine to
the pallet, placed on the lower part of the machine frame by
unscrewing the screws (see figure on the left)
Now it is possible to separate completely the machine from
Level the machine
loosening / tightening
the T.E. screws placed
on the lower part of the
machine frame (see
figure on the right ).
Transport and put the machine in the place selected
for working. Please be careful in doing this procedure
and follow the instructions described in chapter 11-12
