26354600 BACK STOP UNIT
POS. CODE PART NAME QUANTITY
1 00003305 SEEGER E12 4
2 00003424 BEARING 6001 2RS1 4
3 00003520 OR RING 2031 2
4 00004044 SNAP LEVER M6 x 30 2
5 00005127 SELF TAPPING SCREW TC Ø2,2x6,5 ISO1481 4
6 00018307 SCREW VTCEI M8X16 UNI-5931 2
7 00018327 SCREW VTCEI M8X35 UNI-5931 4
8 00018431 SCREW VTBCEI M6X20 ISO-7380 4
9 00018521 WASHER Ø8 UNI-6592 2
10 00018526 WASHER Ø6x18 UNI3351 2
11 00018552 NYLON CAP 4
12 00150802 SCREW VSTEI M8x8 UNI5927 3
13 36000153
THICKNESS PLATE
2
14 36001078 ALIGMENT PIN 2
15 36002065 LH BACK STOP HOLDER 1
16 36002066 RH BACK STOP HOLDER 1
17 36050608 CAM 4
18 36050801 DOWEL 4
19 36054601 FIXED DRILL SLEEVE 2
20 36054602 FIXED DRILL PIN 2
21 36204812 LOCATING BLOCK 1
22 36350607 BACK REINFORCEMENT 35 1
23 36800228 DOWEL M6 2
24 46050613 RH BACK STOP MILLIMETRED RULE 1
25 46050614 LH BACK STOP MILLIMETRED RULE 1
26 46350603 BACK STOP PROFILE 35 1
