RIO 2e, TANGO 2e & TANGO +L Printers USER MANUAL
Page 13 of 33
Types Of Laminate Roll
The Tango +L printer uses two types of laminate film:
Patch Laminate
– This type of laminate roll places a patch
on the surface of the card it will leave a small border around
the patch (typically 1-2mm). The roll comes in 0.6mil and
1.0mil thicknesses and can incorporate a holograph. Custom
holographic designs are available upon request. Contact your
dealer for details.
Overlay Laminate – This type of laminate roll covers the full
card surface from edge to edge with a thin protective film. It
can also incorporate a holograph. Custom holographic designs
are available upon request. Contact your dealer for details.
Details of how to replace both types of laminate roll are shown below.
Load the laminate roll into the laminator following the diagram below for your laminate film type (either Patch or Overlay) .
Make sure both spools are pushed fully towards the back.
IMPORTANT: When loading Pa
tch type laminate roll, ensure the index marks are towards the BACK.
Make sure the film passes through the sensor.
Steps 1 – 5 show how the laminate roll is fitted.
6. Loading the Laminate Roll
