LT20A / LT30 Series
40 (G)
Anfangseinstellungen :
Ausgabe mit Messmodusinformation und
Komparator-Gut/Ausschuss-Ergebnis
1. Byte : Kanal (A oder B)
2. Byte : Aktueller Modus
( N : Aktueller Wert,
P : Spitze/Spitze-Wert,
I : Minimalwert,
A : Maximalwert)
3. Byte : Einheit (M: mm, I: inch)
4. Byte : Komparator-Gut/Ausschuss-
Ergebnis
U:Überschreitung der
Obergrenze
G : Innerhalb des Bereichs
L : Unterschreitung der
Untergrenze
E : Wenn ein Alarm
aufgetreten ist
5. Byte : Vorzeichen (+
oder “–”)
6. bis 12. Byte
: Numerische Daten
(Exempel: 00,0000)
: (+ oder Leerstelle )
3. Ausgangsdatenformat
Das Ausgangsdatenformat hängt von Anfangseinstellungen
ab. (Siehe Seite 16.)
qq
qq
q Normalzustand
Anfangseinstellungen :
Normale Ausgabe (werkseitige Einstellung)
1. Byte : Kanal (A oder B)
2. Byte : Vorzeichen (+
oder “–”)
3. bis 9. Byte : Numerische Daten
(Exempel: 12,3456)
Anfangseinstellungen :
(Ausgabe mit Messmodus-Information)
1. Byte : Kanal (A oder B)
2. Byte : Aktueller Modus
( N : Aktueller Wert,
P : Spitze/Spitze-Wert,
I : Minimalwert,
A : Maximalwert)
3. Byte : Einheit (M: mm, I: inch)
4. Byte : Vorzeichen (+
oder “–”)
5. bis 11. Byte
: Numerische Daten
(Exempel: 00,0000)
